Inverter Pulse Aluminum Mig ART: 322

• Pre-set welding programs for easy set up.
• Step-less infi nite regulation on one single dial.
• Easy to read LCD display.
• Upgradeable for new programs.
• Weld very thin aluminum with full penetration.
• Pulse feature vital for automotive aluminum repair.
• Mig brazing for galvanized steel.
• 220 volt single phase.
• Amperage output 20-200 amps.
• Duty cycle 100% at 120 amps, 60% at 140 amps 20% at 200 amps.
• Synergic programs and pulsed programs are standard 0.6 0.8 0.9 1.0 steel and aluminum 0.8 0.9 Stainless and Silicon Bronze.
• Max. wire spool size Ø 300 mm / 12” – 15 kg / 7 lbs.
• Weight 45 kg / 99 lbs.
• Built in gas cylinder holder.
• Mounted on heavy duty casters for easy mobility.
• Dimensions: 480 x 830 x 825 mm – 19” x 34” x 33”.

Push Pull Gun ART: 2003

• No bulky spool-gun. Wire feed motor built into hand grip.
• Control the current up or down from the handle. On the fly.
• Feeds all solid wires with diameter of 0.6, 0.8 and 1.0.
• Especially suited for aluminum welding.
• Heavy Duty Mig Gun ART: 1242
• 280 amps- 9 ft. – steel liner, ergonomic handle, Euro quick connect.

Heavy Duty Mig Gun ART: 1242

• 280 amps- 9 ft.- steel liner, ergonomic handle, Euro quick connect.

Stand Mig Welding Gun ART: MB15 (not pictured)

• Air-cooled
• Capacity 180 amp with CO2, 150amp mixed gases.
• 60% duty cycle
• Wire Sizes: .023” (0.6mm) through .035” (.09mm)
• Weight : 32.2 oz.
• Length: 10 ft.

322 Display

Art-1242 Heavy duty torch for 322

Art-2003 push pull torch for 322
